Environment Setup

  • In this lab we install all the tools needed to run the remaining ArgoCD labs locally.
  • We create a local Kubernetes cluster using kind and install ArgoCD into it.
  • By the end of this lab you will have a fully functional ArgoCD instance accessible at https://localhost:8080.

What will we learn?

  • How to install kubectl, kind, and the argocd CLI
  • How to create a local Kubernetes cluster with kind
  • How to install ArgoCD via kubectl apply
  • How to access the ArgoCD UI with port-forwarding
  • How to retrieve the initial admin password

Prerequisites

  • Docker installed and running
  • Internet access to pull images and install tools
  • macOS, Linux, or Windows with WSL2

01. Install kubectl

kubectl is the Kubernetes command-line tool used to interact with any cluster.

# macOS (Homebrew)
brew install kubectl

# Linux
curl -LO "https://dl.k8s.io/release/$(curl -sL https://dl.k8s.io/release/stable.txt)/bin/linux/amd64/kubectl"
chmod +x kubectl
sudo mv kubectl /usr/local/bin/

# Verify
kubectl version --client

02. Install kind

kind (Kubernetes IN Docker) runs Kubernetes clusters as Docker containers - ideal for local development.

# macOS (Homebrew)
brew install kind

# Linux
curl -Lo ./kind https://kind.sigs.k8s.io/dl/v0.22.0/kind-linux-amd64
chmod +x ./kind
sudo mv ./kind /usr/local/bin/kind

# Verify
kind version

03. Install ArgoCD CLI

The argocd CLI lets you manage applications, repos, and clusters from the terminal.

# macOS (Homebrew)
brew install argocd

# Linux
curl -sSL -o argocd-linux-amd64 \
  https://github.com/argoproj/argo-cd/releases/latest/download/argocd-linux-amd64
chmod +x argocd-linux-amd64
sudo mv argocd-linux-amd64 /usr/local/bin/argocd

# Verify
argocd version --client

04. Create a Local Kubernetes Cluster

We use kind to spin up a single-node cluster named argocd-labs.

# Create cluster
kind create cluster --name argocd-labs

# Verify the cluster is running
kubectl cluster-info --context kind-argocd-labs
kubectl get nodes

Expected output:

NAME                        STATUS   ROLES           AGE   VERSION
argocd-labs-control-plane   Ready    control-plane   30s   v1.29.x

05. Install ArgoCD

ArgoCD is installed into its own namespace using the official install manifest.

# Create the argocd namespace
kubectl create namespace argocd

# Install ArgoCD
kubectl apply -n argocd \
  -f https://raw.githubusercontent.com/argoproj/argo-cd/stable/manifests/install.yaml

# Wait for all pods to be Ready
kubectl wait --for=condition=Ready pods --all -n argocd --timeout=300s

# Verify all pods are running
kubectl get pods -n argocd

Expected pods:

argocd-application-controller-0      1/1   Running
argocd-dex-server-xxx                1/1   Running
argocd-notifications-controller-xxx  1/1   Running
argocd-redis-xxx                     1/1   Running
argocd-repo-server-xxx               1/1   Running
argocd-server-xxx                    1/1   Running

06. Access the ArgoCD UI

Port-forward the ArgoCD server to access it locally:

# Port-forward in the background
kubectl port-forward svc/argocd-server -n argocd 8080:443 &

# The UI is now available at: https://localhost:8080
# (accept the self-signed certificate warning)

07. Get Initial Admin Password

ArgoCD generates a random initial password stored in a Kubernetes Secret.

# Get the initial admin password
argocd admin initial-password -n argocd

# Or directly via kubectl
kubectl -n argocd get secret argocd-initial-admin-secret \
  -o jsonpath="{.data.password}" | base64 -d && echo

# Login with the CLI
argocd login localhost:8080 \
  --username admin \
  --password $(kubectl -n argocd get secret argocd-initial-admin-secret \
    -o jsonpath="{.data.password}" | base64 -d) \
  --insecure

# Change the password (recommended)
argocd account update-password

Practice

08. Hands-on

  1. Create a kind cluster named argocd-labs and verify the node is Ready:

??? success “Solution”

kind create cluster --name argocd-labs
kubectl get nodes --context kind-argocd-labs
  1. Install ArgoCD and wait until all pods in the argocd namespace are Running:

??? success “Solution”

kubectl create namespace argocd
kubectl apply -n argocd \
  -f https://raw.githubusercontent.com/argoproj/argo-cd/stable/manifests/install.yaml
kubectl wait --for=condition=Ready pods --all -n argocd --timeout=300s
kubectl get pods -n argocd
  1. Port-forward the ArgoCD server and log in with the CLI using the initial admin password:

??? success “Solution”

kubectl port-forward svc/argocd-server -n argocd 8080:443 &
ARGOCD_PASS=$(kubectl -n argocd get secret argocd-initial-admin-secret \
  -o jsonpath="{.data.password}" | base64 -d)
argocd login localhost:8080 --username admin --password "$ARGOCD_PASS" --insecure
argocd version
  1. List all ArgoCD CRDs installed in the cluster:

??? success “Solution”

kubectl get crd | grep argoproj
# Expected output includes:
# applications.argoproj.io
# applicationsets.argoproj.io
# appprojects.argoproj.io

09. Summary

  • kind creates lightweight Kubernetes clusters inside Docker containers - perfect for local ArgoCD labs
  • ArgoCD installs into its own argocd namespace from the official install manifest
  • The argocd-server pod serves both the web UI and the gRPC API for the CLI
  • The initial admin password is stored in the argocd-initial-admin-secret Kubernetes Secret
  • Always change the initial admin password after first login
